| Attachement do Stepper Motor Size | NEMA17/NEMA23 |
| Positioning precision (mm) | ±0.05 |
| Motion Transfer | Trapezoidal Lead Screw |
| Rotary Speed (rpm) | 1000 |
| Stroke Range (mm) | 50-800 |
| MA - max. torque (Nm) | 15 |
| MB - max. torque (Nm) | 16 |
| MC - max. torque (Nm) | 20 |
| Screw Lead (mm/rot) | 1 | 2 | 5 | 10 |
| Max speed (mm/s) @300rpm | 5 | 10 | 25 | 50 |
| Max Horizontal Load (kg) | 10 | 15 | 27 | 22 |
| Max Vertical Load (kg) | 3 | 5 | 10 | 9 |
| Attachement do Stepper Motor Size | NEMA23/NEMA34 |
| Positioning precision (mm) | ±0.05 |
| Motion transfer | Trapezoidal screw |
| Speed of rotation (ot/min) | 1000 |
| Stroke Range (mm) | 50-800 |
| MA - max. torque (Nm) | 30 |
| MB - max. torque (Nm) | 32 |
| MC - max. torque (Nm) | 58 |
| Pitch motion bolt (mm/ot) | 2 | 5 | 10 | 16 | 20 |
| Max speed of shift (mm/s) @300rpm | 10 | 25 | 50 | 80 | 100 |
| Maximum horizontal load (kg) | 17 | 46 | 29 | 24 | 15 |
| Maximum vertical load (kg) | 6 | 17 | 12 | 11 | - |
| Attachement do Stepper Motor Size | NEMA23/NEMA34 |
| Positioning precision (mm) | ±0.05 |
| Motion transfer | Trapezoidal screw |
| Speed of rotation (ot/min) | 1000 |
| Stroke Range (mm) | 50-800 |
| MA - max. torque (Nm) | 30 |
| MB - max. torque (Nm) | 32 |
| MC - max. torque (Nm) | 58 |
| Pitch motion bolt (mm/ot) | 2 | 5 | 10 | 16 | 20 |
| Max speed of shift (mm/s) @300rpm | 10 | 25 | 50 | 80 | 100 |
| Maximum horizontal load (kg) | 23 | 60 | 39 | 32 | 20 |
| Maximum vertical load (kg) | 8 | 23 | 16 | 14 | - |
| Description version | Working ambient temperature | Vaccum Class (Pa) | Temperature sensor |
| Vaccum Class 01 | -20...+85 | - | Optional |
| Vaccum Class 02 | -40...+85 | - | Optional |
| Vaccum Class 03 | -60...+85 | 10^1 | Optional |
| Vaccum Class 04 | -20...+150 | 10^3 | Optional |
| Vaccum Class 05 | -20...+200 | 10^7 | Optional |
| Vaccum Class 06 | -100...+40 | 10^7 | Optional |
| Vaccum Class 07 | -200...+40 | 10^7 | Optional |
| Vaccum Class 08 | Customized | Customized | Optional |
