Stepper Motor NEMA17 with Vacuum rated Planetary Gearbox

Stepper Motor and Planetary Gearbox are both rated do Vacuum Environment 10^-7Torr (13^-6 Pa)
Working Points for High Torque and High Speed shown:
High Torque : 0.23Nm at 100 rpm
Top Speed : 0.05Nm at 750 rpm


RatioWorking
Point		Output
Speed
[rpm]		Output
Torque
[Nm]		DatasheetQuote
3High Torque330.54linklink
3Top Speed2500.14linklink
5High Torque200.9linklink
5Top Speed1500.23linklink
8High Torque12.51.44linklink
8Top Speed940.36linklink
10High Torque101.8linklink
10Top Speed750.45linklink
15High Torque72.7linklink
15Top Speed500.68linklink
25High Torque44.5linklink
25Top Speed301.13linklink
40High Torque2.57.2linklink
40Top Speed191.8linklink
80High Torque1.2514.4linklink
80Top Speed9.383.6linklink
120High Torque0.8321.6linklink
120Top Speed6.255.4linklink
200High Torque0.536linklink
200Top Speed3.759linklink

Torque and Speed on the Gearbox Output Shaft for various Gearbox Ratios

Stepper Motor with Planetary Gearbox for Vacuum Environment - NEMA17 - Dimensions


Both Stepper Motor na Gearbox are Rated for Vacuum Environment 10^-7Torr

Request a Quote for NEMA17 Vacuum rated Stepper and Gearbox:

Request Quote Request Quote Request Quote

Stepper Motor NEMA23 with Vacuum rated Planetary Gearbox

Stepper Motor and Planetary Gearbox are both rated do Vacuum Environment 10^-7Torr (13^-6 Pa)
Working Points for High Torque and High Speed shown:
High Torque : 0.85Nm at 100 rpm
Top Speed : 0.35Nm at 750 rpm


RatioWorking
Point		Output
Speed
[rpm]		Output
Torque
[Nm]		DatasheetQuote
3High Torque332.3linklink
3Top Speed2500.95linklink
5High Torque203.83linklink
5Top Speed1501.58linklink
8High Torque136.12linklink
8Top Speed942.52linklink
10High Torque107.65linklink
10Top Speed753.15linklink
15High Torque711.48linklink
15Top Speed504.73linklink
25High Torque419.13linklink
25Top Speed307.88linklink
40High Torque330.6linklink
40Top Speed1912.6linklink
80High Torque1.2561.2linklink
80Top Speed9.3825.2linklink
120High Torque0.8391.8linklink
120Top Speed6.2537.8linklink
200High Torque0.5153linklink
200Top Speed3.7563linklink

Torque and Speed on the Gearbox Output Shaft for various Gearbox Ratios

Stepper Motor with Planetary Gearbox for Vacuum Environment - NEMA23 - Dimensions


Both Stepper Motor na Gearbox are Rated for Vacuum Environment 10^-7Torr

Request a Quote for NEMA23 Vacuum rated Stepper and Gearbox:

Request Quote Request Quote Request Quote

Stepper Motor NEMA34 with Vacuum rated Planetary Gearbox

Stepper Motor and Planetary Gearbox are both rated do Vacuum Environment 10^-7Torr (13^-6 Pa)
Working Points for High Torque and High Speed shown:
High Torque : 5.3Nm at 100rpm
Top Speed : 1.2Nm at 1000rpm


RatioWorking
Point		Output
Speed
[rpm]		Output
Torque
[Nm]		DatasheetQuote
3High Torque3314.31linklink
3Top Speed3333.24linklink
5High Torque2023.85linklink
5Top Speed2005.4linklink
8High Torque1338.16linklink
8Top Speed1258.64linklink
10High Torque1047.7linklink
10Top Speed10010.8linklink
15High Torque771.55linklink
15Top Speed6716.2linklink
25High Torque4119.25linklink
25Top Speed4027linklink
40High Torque3190.8linklink
40Top Speed2543.2linklink
80High Torque1.25381.6linklink
80Top Speed12.586.4linklink
120High Torque0.83572.4linklink
120Top Speed8.33129.6linklink
200High Torque0.5954linklink
200Top Speed5216linklink

Torque and Speed on the Gearbox Output Shaft for various Gearbox Ratios

Stepper Motor with Planetary Gearbox for Vacuum Environment - NEMA34 - Dimensions


Both Stepper Motor na Gearbox are Rated for Vacuum Environment 10^-7Torr

Request a Quote for NEMA34 Vacuum rated Stepper and Gearbox:
